PU Elastomer Moderate Temperature Casting Machine

wheels and other polyurethane elastomer products; color paste can be added to the mixing device. Ⅳ.Working conditions: V. Main parameters: VI.Product display:

Send Inquiry

Chat Now

wheels and other polyurethane elastomer products; color paste can be added to the mixing device.

Ⅳ.Working conditions:

Component Name	Mixing ratio	Temperature(℃)	Viscosity (CPS)
A (prepolymer) polyhydric alcohols	100	20-85°C	200-2000
B (curing agent) modifiedMDI	25-110	20-85°C	200-2000
C Color paste	0.1-1	Room temperature	50-2000

V. Main parameters:

Item/Model	CPU20J-Z1	CPU20J-Z2	CPU20J-Z3	CPU20J-Z4	CPU20J-Z5
Total discharge amount(g/min)	1-5	2.5-7	6-18	10-30	15-60
A tank capacity(L)	80	80	120	120	120
B tank capacity(L)	80	80	120	120	120
Pouring head stirring speed(r/min)	4000-5000	4000-5000	4000-5000	4000-5000	4000-5000
Height from ground(mm)	1200	1200	1200	1300	1300
Total power(kw)	19	19	22	22	28

VI.Product display:
